Dan Logitech's Analog Benchtop Hotplate, catalog number 730.DNAG, features a single knob operation with a hot top indicator, IP 22 Class, and has a capacity of 2000 ml.
Icons display product features such as single knob operation, hot top indicator, 2000ml capacity, chemical resistance, an ambient temperature range up to 350°C, Celsius/Fahrenheit toggle, and IP 21 protection.
  • UL Certificate
  • CSA Certificate
  • CE Certificate
Dan Logitech's Analog Benchtop Hotplate, catalog number 730.DNAG, features a single knob operation with a hot top indicator, IP 22 Class, and has a capacity of 2000 ml.

Analog Benchtop Hotplate

Dan Logitech's Digital Magnetic Stirrer with Ceramic Hotplate, catalog number 500.DNDG, has a neoceram top plate, a toggle button for temperature, an inbuilt PT100 temperature sensor, an IP21 rating, & capacity up to 5000ml. Hotplate Magnetic Stirrer

Catalog no: 730.DNAG

(SS CERAMIC COATED TOP)

  • PU coated aluminium alloy moulded body
  • Hot top indicator for temperatures above 50°C
  • Heat reach Indicator to ensure correct temperature of plate surface
  • Error indicator for failures
  • Single knob operation

Price: On Request

Item Code Volts/Hz WattsPriceQty / Enquiry
730.DNAG.01230/50650 On Request
730.DNAG.02115/60650 On Request

Description

Technical Specification :

Heating plate material:Stainless Steel 304 Grade Ceramic Coated
Dimension of heating plate:150 Ø
Temperature range:Ambient to 350°C approx
Dimensions:273 x 160 x 102mm
Weight:2.0 kg
Permissible ambient temperature:5 – 40 °C
Permissible relative humidity:80%
Frequency:50/60Hz
Voltage:230/115V
DIN EN 60529:IP 21

Download

DAN Logitech Instruments Catalogue

Additional information

PD

Item Code:730.DNAG.01, Volts/Hz:230/50, Watts:650, Item Code:730.DNAG.02, Volts/Hz:115/60, Watts:650

Item CodeAccessories
850.800.01:Rod Stainless Steel Length 400 mm, Ø 12 mm
850.800.02*:Magnetic Stirring bar 35 mm x 8 mm
850.800.04:Boss head
