Dry Block Heater

Catalog no: 740.DNEU.01

Item Code	Volts/Hz	Watts	No of Block	Price
740.DNEU.01	230/50	170	Single block	On Request
740.DNUS.01	115/60	170	Single block	On Request
750.DNEU.01	230/50	340	Double block	On Request
750.DNUS.01	115/60	340	Double block	On Request

Technical Specification :

Number of blocks	:	1	2
Heat output	:	170W	340W
Heating temperature range	:	120°C	120°C
Temperature display	:	YES	YES
Adjustment & display resolution	:	1K	1K
Connection for ext. temp probe	:	DIN	DIN
Temperature sensor	:	PT 100	PT 100
Set-up plate material	:	Aluminium alloy	Aluminium alloy
Set-up plate dimensions	:	95 x 76 x 51mm	95 x 76 x 51mm x (2 block)
Fixed safety circuit	:	130°C	130°C
Timer	:	YES	YES
Time setting range	:	1-5999	1-5999
Counter	:	YES	YES
Counter setting range	:	1-5999	1-5999
Dimensions	:	160 x 80 x 71mm	163 x 106 x 332mm
Weight of body	:	2.8 kg (Approx.)	2.9 kg (Approx.)
Permissible ambient temp	:	5 – 40°C	5 – 40°C
Permissible relative humidity	:	80%	80%
Voltage	:	230/115V	230/115V
Frequency	:	50/60Hz	50/60Hz
DIN EN 60529	:	IP 21	IP 21

DBH	Item Code:740.DNEU.01, Volts/Hz:230/50, Watts:170, No of Block:Single block, Item Code:740.DNUS.01, Volts/Hz:115/60, Watts:170, No of Block:Single block, Item Code:750.DNEU.01, Volts/Hz:230/50, Watts:340, No of Block:Double block, Item Code:750.DNUS.01, Volts/Hz:115/60, Watts:340, No of Block:Double block
