Digital Magnetic Stirrer Multi Position with Heating

716.DNAG-min Analogue Magnetic Stirrer Multi Position With Hotplate
Analogue Heating Mantle With Stirrer BlackDiamond™: Analogue Heating Mantle with Stirrer

Catalog no.: 415.DNDG

Labs-Connect™ Technology

  • Wifi enabled with worldwide access
  • Robust & durable metallic body
  • Designed for simultaneous heating and stirring
  • Suitable for continuous unsupervised operation
  • Includes anti-slip silicone mat for safety
  • Motorless, noise free & continuous stirring function
  • Uniform temperature distribution across the heating plate
  • Timer & Auto power ‘ON’ option
  • Hot top indicator for user safety
  • 6 Stirring modes for convenience
  • Constant stirring speed even with varying viscosity
  • Cool body operation for user safety
  • Error code display for failures

Price: On Request

Item Code WattsHeatWIFIPriceQty / Enquiry
415.DNWDG.01750YesYes On Request
415.DNDG.01750YesNo On Request
414.DNDG.0150NoNo On Request

Description

Technical Specification :

Set-up plate material:Aluminum
Silicone mat:Yes
Number of stirring positions:15
Stirring position distance:90 mm
Speed range:0-1000 RPM
Speed control:10 RPM/click
Stirring capacity:6 Ltr. (400mlx15)
Max. stirring bar length:30×8 mm
Heating temperature range:Room temp. to 120°C
Display type:LED
Input Type:Key Button
Adjustable safety circuit min.:50°C
Adjustable safety circuit max.:130°C
Timer range:1min – 99:59min
Set-up plate dimensions:274×504 mm
Dimensions:281x181x609 mm
Weight:10.6 kg (Approx.)
Permissible ambient temperature:5 – 40°C
Permissible relative humidity:80%
Voltage:100-240 V
Frequency:50/60 Hz
DIN EN 60529:IP 40

Download

  • No brochure available.

Additional information

PD

Item Code:415.DNWDG.01, Watts:750 ,Heat:Yes ,WIFI:Yes, Item Code:415.DNDG.01, Watts:750 ,Heat:Yes ,WIFI:No, Item Code:414.DNDG.01, Watts:50 ,Heat:No ,WIFI:No

Item Code Accessories
411.00.01:(15) Magnetic Stirring bar 30mm x 8mm
