Digital Magnetic Stirrer With Glass ceramic top Hotplate
Catalog no: 500B.DNDG.01
NEOCERAM™(Glass Ceramic Top)
- PU coated aluminum alloy moulded body
- Dual Knob operation for independent temperature & stir control
- Selection of hotplate or probe for temperature control
- Hot top indicator for user safety
- Adjustable temperature limit safety cut-off for top plate & probe
- Temperature control in °C & °F
- Error code display for failures
- BLAC motor withstands voltage fluctuations
- User safety spill away design
- Enquire Now
- Specifications
- Download
- Included Accessories
- Additional information
| Item Code | Volts/Hz | Watts | Price | Qty / Enquiry |
|---|---|---|---|---|
| 500B.DNDG.01 | 230/50 | 1300 | On Request | |
| 500B.DNDG.02 | 115/60 | 1300 | On Request |
Description
Technical Specification :
| Heating plate material | : | Glass Ceramic Top Plate |
| Dimension of heating plate | : | 180 x 180mm |
| Display windows | : | LCD WHITE |
| Speed range | : | ~2000 RPM |
| Heat output | : | 1300W |
| Heating capacity | : | 5 Ltr. |
| Stirring capacity | : | 20 Ltr. |
| Temperature range | : | Ambient to 550°C |
| Adjustable safety cut off | : | 580°C |
| Control accuracy of sensor | : | ± 1K |
| Weight | : | 5.2 kg |
| Permissible ambient temp. | : | 5 – 40°C |
| Permissible relative humidity | : | 80% |
| Dimensions | : | 378 x 220 x 103mm |
| Frequency | : | 50/60Hz |
| Voltage | : | 230/115V |
| DIN EN 60529 | : | IP 21 |
| Item Code | Accessories | |
| 550.500.01 | : | Rod Stainless Steel length 500 mm, Ø 12 mm |
| 550.500.02 | : | Magnetic Stirring bar 25 mm x 8.25 mm |
| 550.500.03 | : | PT 1000 probe |
| 550.500.04 | : | Clamp with Boss head |
Additional information
| 500B.DNDG | Item Code:500B.DNDG.01, Volts/Hz:230/50, Watts:1300, Item Code:500B.DNDG.02, Volts/Hz:115/60, Watts:1300 |
|---|
