Dan Logitech's 3-Multiposition Magnetic Stirrer Hotplate, catalog number 716.DNAG, has a stainless steel top, a hot top indicator, an inbuilt PT100 temperature sensor, an IP21 rating & capacity up to 2000 ml for each position.
Icons displays the product feature like 1350W heat output, 1600 RPM stirring, chemical resistant, temperature range from ambient to 350°C, capacity 3×2000ml, PT 100 temperature sensor probe, hot top indicator, Celsius/Fahrenheit switch, and IP 21 protection class.
  • CE Certificate
Dan Logitech's 3-Multiposition Magnetic Stirrer Hotplate, catalog number 716.DNAG, has a stainless steel top, a hot top indicator, an inbuilt PT100 temperature sensor, an IP21 rating & capacity up to 2000 ml for each position.

3 Position Hotplate Stirrer

Dan Logitech's Digital Multi-Position Magnetic Stirrer with Heating, catalog number 411.DNDG. The display features 6 mode choices and 5 stirring positions, capable of stirring at 1000 RPM with an IP 21 rating. It has a stirring capacity up to 2000 ml. 5 Multi Position Hotplate Stirrer
Dan Logitech's Magnetic Stirrer Hotplate with a round top, catalog number 610.DNAG, features dual knob for heat & stir control, hot top indicator & an inbuilt PT 100 temperature sensor. It has an IP 22 rating and a capacity up to 2000ml. Magnetic Stirrer Hotplate

Catalog no: 716.DNAG.01

(SS TOP)

  • PU coated aluminum alloy moulded body
  • Three sets of dual knob operation for temperature & stir control
  • Inbuilt temperature sensor for outstanding accuracy and control
  • Hot top indicator for temperatures above 50°C for each station
  • Heat reach Indicator to ensure correct temperature of plate surface
  • Error code display for failures

Price: On Request

Item Code Volts/Hz WattsPriceQty / Enquiry
716.DNAG.01230/50(450x3)1350 On Request
716.DNAG.02115/60(450x3)1350 On Request

Description

Technical Specification :

Heating plate material:Stainless Steel
Dimension of heating plate:Ø150mm
Stirring capacity:2 Ltr each station
Speed range:1600RPM
Stirring position:3
Maximum stirring range:Can use upto 80mm bar Lower speed
Maximum plate temperature:350°C
Overall dimensions:505 x 246 x 195mm
Plate dimensions:504 x 175 x 30mm
Weight:7.0 kg (Approx.)
Permissible ambient temp.:5-40°C
Permissible relative humidity:80%
Frequency:50/60Hz
Voltage:230/115V
DIN EN 60529:IP 21

Download

DAN Logitech Instruments Catalogue

Additional information

PD

Item Code:716.DNAG.01, Volts/Hz:230/50, Watts:(450×3)1350, Item Code:716.DNAG.02, Volts/Hz:115/60, Watts:(450×3)1350

Item Code Accessories
850.800.01:Rod Stainless Steel Length 400mm, Ø 12mm
850.800.02*:Magnec Srring bar 35mmx8mm
850.800.04:Boss head
